100W 12V Renogy Monocrystalline Solar Panel for RVs, Farms & Off-Grid

Product description

1 25% High-Efficiency

2 Provide More Output

3 Premium Quality

4 High Temp Advantage

16BB for Higher Conversion Efficiency

Advanced 16BB cell technology maximizes energy conversion while enhancing durability by minimizing the risk of microcracks.

Stronger Aluminum Frame for Enhanced Durability

Crafted from aluminum alloy over 1.1mm thick, this solar panel boasts a sturdier frame compared to competitors’, ensuring enhanced durability.

Compatible with 99% of Charge Controllers

This panel, with an open-circuit voltage of less than 25V, is compatible with various MPPT/PWM charge controllers.

Effortless Power, Compactly Installed

This 100W n-type solar panel is 8% lighter and 11% smaller than a p-type PERC 100W solar panel. This makes installation easier and allows for more space for panel expansion.

1 Class B Van

2 Class C RV

3 Marine

Specifications

Max Power at STC 100W Open Circuit Voltage 22.79V Short Circuit Current 5.31A Optimum Operating Voltage 19.97V Optimum Operating Current 5.01A Cell Efficiency 25% Dimensions 34.1×22.8×1.2in/865x578x30mm Weight 13.0lbs/5.9kg Maximum System Voltage 600VDC Maximum Series Fuse Rating 15A Module Efficiency 20.0% Operating Temperature -40°F~194°F / -40℃~90℃

What does off-grid and on-grid mean ?

On-grid simply means solar power equipment (array or solar panel) is connected to the electrical grid, while off-grid refers to systems that are not connected to the grid and therefore store the generated power for later use.

Why is my solar panel under producing ?

Solar panel performance may be hindered for a number of reasons. Most commonly environmental conditions such as indirect sunlight, temperature rise, cloudy sky, and dirt and stain build up on the top glass will cause a reduced power output.

How should I connect solar panels in my electrical circuit (series vs parallel)

Connecting solar panels in series will have the effect of adding up their operating voltage output, while system current output will be the same as that for one panel. While, connecting solar panels in parallel will have a different effect;

How many solar panels do I need ?

To determine solar panel needs, calculate the power load (Watts) and capacity (Watt-hours). Size the battery bank based on minimum capacity, then adjust panel quantity or power input accordingly.

What is the meaning of 12V in the product title，Why is this value different from the voltage of the solar panel？

When you open the product page, you will see a title like “xxx Watt 12 Volt Solar Panel”. The “12V” here does not refer to the voltage of this solar panel (VOC or VMP), but to the fact that one xxxW solar panel is suitable for 12V system.

𝗠𝗮𝗿𝗸𝗲𝘁-𝗟𝗲𝗮𝗱𝗶𝗻𝗴 𝟮𝟱% 𝗖𝗼𝗻𝘃𝗲𝗿𝘀𝗶𝗼𝗻 𝗘𝗳𝗳𝗶𝗰𝗶𝗲𝗻𝗰𝘆 – Renogy’s 100w solar panel features A+ grade n-type solar cells, achieving an impressive 25% conversion efficiency. This slolar panel delivers 20W more power output compared to standard solar panels 100 watt of the same design, making it an excellent choice for solar energy solutions.
𝟭𝟲𝗕𝗕 𝗧𝗲𝗰𝗵𝗻𝗼𝗹𝗼𝗴𝘆 𝗳𝗼𝗿 𝗘𝗻𝗵𝗮𝗻𝗰𝗲𝗱 𝗣𝗲𝗿𝗳𝗼𝗿𝗺𝗮𝗻𝗰𝗲 – Employing advanced 16BB N-Type solar panel technology, this 100 watt solar panel enhances photoelectric conversion efficiency while minimizing the risk of hot spots and hidden cracks. This results in a longer lifespan and superior performance for your solar panel kit.
𝗖𝗼𝗺𝗽𝗮𝗰𝘁 𝗬𝗲𝘁 𝗣𝗼𝘄𝗲𝗿𝗳𝘂𝗹 – Renogy 100w solar panel is 11% smaller and 8% lighter than its predecessor, providing the same power output in a more compact, space-saving design—ideal for tight spaces in Mini Van Life.
𝗛𝗶𝗴𝗵 𝗧𝗲𝗺𝗽𝗲𝗿𝗮𝘁𝘂𝗿𝗲 𝗣𝗲𝗿𝗳𝗼𝗿𝗺𝗮𝗻𝗰𝗲 – The Renogy 100 watt solar panel features a low temperature coefficient of -0.29%/℃, which reduces power loss in high temperatures. This characteristic significantly boosts power generation, especially during summer months or in extremely hot climates.
𝗕𝘂𝗶𝗹𝘁 𝘁𝗼 𝗟𝗮𝘀𝘁 – With an IP65 rating, this 12v solar panel is designed to endure snow, rain, and heat for decades. The low-iron tempered glass and corrosion-resistant aluminum frame of the renogy solar panels ensure exceptional durability and performance in all weather conditions.
𝗟𝗼𝗻𝗴-𝗧𝗲𝗿𝗺 𝗥𝗲𝗹𝗶𝗮𝗯𝗶𝗹𝗶𝘁𝘆 – Renogy solar panels with low degradation (≤1% in the first year, ≤0.4% annually). It’s backed by a 10-year material and workmanship commitment, plus a 25-year performance guarantee at 80% output.
